| 1 |
缸徑*行程 Bore×stroke(mm) |
92×66 |
| 2 |
排量Displacement(ml) |
439 |
| 3 |
壓縮比Compression ratio |
8.3: 1 |
| 4 |
啟動方式Starting system |
反沖式 Recoil start |
| 5 |
發動機形式 Engine type |
單缸、四沖程、強制冷風、傾斜 |
| 6 |
Single cylinder,4-stroke, forced air-cooled,OHV 250 |
| 7 |
最大輸出功率Max. output HP(KW)/rpm |
16HP/3600 |
| 8 |
最大扭矩Max. torque (N.m/rpm) |
24/2500 |
| 9 |
燃油容積 Fuel tank capacity(L) |
6.5 |
| 10 |
機油容積 Oil capacity(L) |
1.1 |
| 11 |
最低燃油消耗 Fuel consumption(g/kw.h) |
≤374 |
| 12 |
點火方式 Ignition system |
無觸點晶體管點火 Transistor magneto |
| 13 |
安裝尺寸 |
φ12-195*95 T-31 |
| 14 |
包裝尺寸Packing measure (L×W×H) (mm) |
500×430×511 |
| 15 |
凈重/毛重G.W./N.W.(kg) |
31/33 |
| 16 |
20英尺集裝箱裝貨數Qty20'' purchase |
236 |
